SJZ type conical twin-screw extruder is suitable for all kinds of PVC powder extrusion molding special equipment, equipped with different molds and auxiliary machines can produce all kinds of PVC plastic pipes, profiles, plates, sheets, bars and granulation.
Used for pipe extrusion
model | SJZ45/90 | SJZ50/105 | SJZ55/110 | SJZ65/132 | SJZ80/156 | SJZ92/188 |
Transmission power | 15 | 18.5 | 22 | 37 | 55 | 110 |
The screw diameter
| 45/90 | 51/105 | 55/110 | 65/132 | 80/156 | 92/188 |
The screw rotation speed | 45 | 45 | 45 | 45 | 34.7 | 34.7 |
PVC產(chǎn)量
| 100 | 120 | 150 | 250 | 450 | 800 |
Used for extruding profiles (wood plastic)
model | SJZ45/90 | SJZ50/105 | SJZ55/110 | SJZ65/132 | SJZ80/156 | SJZ92/188 |
Transmission power
| 15 | 18.5 | 22 | 30-37 | 55 | 110-132 |
The screw diameter | 45/90 | 51/105 | 55/110 | 65/132 | 80/156 | 92/188 |
The screw rotation speed | 34.7 | 34.7 | 34.7 | 34.7 | 34.7 | 34.7 |
PVC production | 60-80 | 80-100 | 120 | 150-250 | 250-400 | 500-700 |
